The SEMCAD X Matterhorn ELF Solution comprises a family of quasi-static solvers for modeling extremely low frequency (ELF) and static applications, and movements in static fields. The novel implementation of electro and magnetic static and quasi-static approximations of Maxwell’s equation on a rectangular grid significantly extends the performance of SEMCAD X Matterhorn. Seamless integration into our highly advanced user-friendly GUI supports expanded applications in highly complex structures.

Application Areas	Wireless power transfer (WPT) simulations for mobile, automotive, etc. Assessment of inductive (Qi) and resonant (AFA) systems Exposure and WPT compliance assessment Coil design and optimization EM and electromechanical devices for industrial systems Accurate design of capacitance and inductance Insulation design
Selected Features	3D magnetostatic (vector potential + Biot-Savart) and magneto quasistatic simulations 3D Electrostatic (ES) and electro quasi-static (EQS) simulation Generalized Huygens source FEM-based (rectilinear grids), MPI parallelized Use of magnetic field data measured using MAGPy as the source to simulate induced field in a phantom Automated simulation & analysis process for WPT compliance assesment
